Engine compartment

(2.7 Gasoline)
(2.7 Gasoline)

1. Power steering fluid reservoir 2. Brake & Clutch fluid reservoir 3. Air cleaner
4. Fuse and Relay box
5. Windshield washer fluid reservoir 6. Engine oil level dipstick 7. Coolant reservoir cap 8. Engine oil filler cap 9. Automatic transaxle fluid level dipstick (Vehicle with Automatic Transaxle) 10. Radiator cap
11. Battery

CAUTION:
When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic cover of the engine is not damaged.

(2.0 Gasoline)
(2.0 Gasoline)

1. Power steering fluid reservoir 2. Engine oil filler cap 3. Brake & Clutch fluid reservoir 4. Air cleaner
5. Fuse and Relay box
6. Windshield washer fluid reservoir 7. Engine oil level dipstick 8. Coolant reservoir cap 9. Automatic transaxle fluid level dipstick (Vehicle with Automatic Transaxle) 10. Radiator cap
11. Battery

CAUTION:
When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic cover of the engine is not damaged.
